P/N	Size (Inch)	Dot Format	A.A. (mm)	Outline Size (mm)	Brightness (nits)	Interface	Touch Panel	Remarks
NL0145BMG	1.45	128XRGBx128	26.04x26.04	32.36x38.00	140	CPU	-	-
NL0177BZG	1.77	128xRGBx160	28.03x35.04	34.70x46.70	180	SPI	-	-
NL0200DZG	2.00	176xRGBx220	31.68x39.60	37.68 x 51.30	220	CPU	-	-
NL0200BMG	2.00	240xRGBx320	30.24x40.32	38.03x51.56	220	CPU	Optional	-
NL0200CMG	2.00	220xRGBx176	38.28x30.62	46.40x42.80	220	CPU	-	-
NL0220AMG	2.20	240xRGBx320	33.84x45.12	40.10x55.20	220	CPU	-	-
NL0220BMG	2.20	240xRGBx320	33.84x45.12	40.60x56.60	90	RGB	-	Transflective
NL0234AMG-1	2.36	320xRGBx240	46.75x35.06	51.00x45.80	250	CPU	-	-
NL0236BUG	2.36	320xRGBx240	48.00x36.00	53.00x46.42	203	CPU/RGB	-	-
NL0240AMG	2.40	240xRGBx320	36.72x48.96	42.72x60.26	250	CPU	Optional	-
NL0250AMG	2.50	960xRGBx240	49.92x37.44	59.63x42.94	500	RGB/CCIR	-	-
NL0270BMG	2.70	320xRGBx240	54.00x 40.50	65.50x46.60	300	RGB/CCIR	-	-
NL0280AMG	2.80	240xRGBx400	36.72x61.20	42.42x72.80	220	CPU	Optional	-
NL0280BMG-T	2.80	240xRGBx320	43.20x57.60	50.00x69.20	250	CPU	Optional	-
NL0300BZG	3.00	240xRGBx400	38.88x64.80	47.04x77.00	180	CPU/RGB	Optional	-
NL0320FZG	3.20	240xRGBx400	41.76x69.60	47.60x80.90	180	CPU	Optional	-
NL0320CMG	3.20	240xRGBx400	41.76x69.60	47.40x81.20	350	RGB	-	-
NL0347AMG	3.47	320xRGBx480	48.96x73.44	55.26x84.69	300	CPU/RGB	Optional	Vertically-Aligned
NL0350KZG	3.50	320xRGBx240	70.08x52.56	76.90x64.00	300	RGB	Optional	-
NL0350AMG	3.50	320x(RGB)x240	70.08x52.56	76.90x64.00	600	RGB	-	-
NL0350BMG-1	3.50	240xRGBx320	53.64x71.52	64.00x85.00	125	RGB	Optional	Transflective
NL0350CDG	3.50	320xRGBx240	70.08x52.56	86.40x64.50	250	CPU	Optional	-
NL0350ISG	3.50	480xRGBx800	45.36x75.60	51.16x86.45	500	RGB	-	Transflective
NL0350DMG	3.50	480xRGBx272	77.40x43.86	89.50x51.76	300	CPU/RGB	-	-
NL0400BZG	4.00	320xRGBx240	82.08x61.56	92.70x75.10	300	RGB	-	-
NL0430EZG	4.30	480xRGBx272	95.04x53.86	105.50x67.20	280	RGB	Optional	-
NL0470BMG	4.70	480xRGBx272	103.68x58.75	114.30x72.50	250	RGB	Optional
NL0500AIG	5.00	640xRGBx480	101.57x76.18	117.65x88.43	200	RGB	-	-
NL0560AIG	5.60	640xRGBx480	112.89X84.67	126.50X100.00	350	RGB	Optional	-
NL0570ADG	5.70	640xRGBx480	115.20x86.40	127.00x98.43	400	RGB	Optional	-
NL0570BDG	5.70	640XRGBX480	115.20x86.40	127.00x98.43	500	RGB	Optional	Outdoor
NL0570CDG	5.70	320xRGBx240	115.20x86.40	127.00x98.43	250	RGB	Optional	-
NL0570JDG-T	5.70	640x(RGB)x480	115.20x86.40	142.75x113.95	340	RGB	Integrated	Capactive Touch
NL0570FMG	5.70	320XRGBX240	115.20X86.40	144.00x104.60	400	RGB	Optional	-
NL0570GMG	5.70	640xRGBx480	115.20x86.40	144.00x104.60	400	RGB	-	-
NL0600BMG	6.00	800xRGBx480	133.20X73.80	145.50x87.80	350	RGB	Optional	-
NL0620AMG	6.20	800xRGBx480	137.40x77.28	155.20x88.20	400	RGB	Optional	-
NL0700BIG-1	7.00	800xRGBx480	154.08x85.92	164.90x100.00	250	RGB	Optional	-
NL0700IMG-T-2	7.00	800xRGBx480	154.08x85.92	166.58x112.5	300	RGB	Integrated	Capactive Touch
NL0700CMG	7.00	800xRGBx600	141.00x105.75	155.50x118.70	200	RGB	-	-
NL0700JMG	7.00	1024XRGBx600	153.60x90.00	165.75x105.39	250	RGB	-	-
NL0700DDG	7.00	800xRGBx480	152.40x91.44	165.00x104.00	320	LVDS	Optional	-
NL0800AIG	8.00	800xRGBx480	176.44x99.36	192.80x116.90	450	RGB	-	-
NL0800BIG-2	8.00	800xRGBx600	162.00x121.50	183.00x141.00	250	RGB	Optional	-
NL0900BMG	9.00	800xRGBx480	198.00x111.70	211.10x126.50	250	RGB	Optional	-
NL1010AGG	10.1	1024xRGBx600	222.72x125.28	235.00x145.80	200	LVDS	Optional	-
NL1020AIG	10.2	800xRGBx480	222.0x132.48	235.0x145.8	250	LVDS	-	-
NL1040EZG	10.4	640xRGBx480	211.20x158.40	246.50x179.40	350	RGB	-	-
NL1040AMG	10.4	800xRGBx600	211.20x158.40	236.00x176.90	400	LVDS	Optional	-
NL1040FIG	10.4	800xRGBx600	211.20x158.40	228.40x175.40	250	RGB	-	-

Note:

Wide Range LCD’s Technologies

Small-medium size TFT:
From 1” to 10.4”

Module technology:
SMT, COB, COG, TAB, COF

Driving board technology:
From 1” to 10.4”
